Sungei Bedok MRT Station

DT37TE31
Sungei Bedok
双溪勿洛 | சுங்கை பிடோக்
Sungei Bedok TEL Station Diagram
Address
Lines Served   Downtown Line
  Thomson-East Coast Line
Operator SBS Transit (DTL)
SMRT Trains (TEL)
Structure Underground
Platform Island
Opening Year 2024

Sungei Bedok MRT Station (DT37 / TE31) is an underground interchange station along the Downtown Line Stage 3 Extension (DTL3e) and the Thomson-East Coast Line (TEL) Stage 5. It is built just off Upper East Coast Road and Bedok Road, bringing rail connectivity to residential developments around the area.

Taking its name from the nearby river, Sungei Bedok station serves Eastwood Centre, Bedok Food Centre and many private homes and condominiums in the vicinity.

The station is targeted for completion by Year 2024, where it will serve as the second interchange station between the DTL and TEL after Stevens, as well as being the eastern terminus of both lines (until the opening of the TEL extension to Tanah Merah via Changi Airport T5). It is also located close to East Coast Integrated Depot, which serves both the DTL and TEL.


First / Last Train Timings

Downtown Line – DT37 Sungei Bedok
Destination First Train Last Train
Weekdays
& Sat
Sun &
Public Holidays
Daily
DT1 Bukit Panjang
Thomson-East Coast Line – TE31 Sungei Bedok
Destination First Train Last Train
Weekdays
& Sat
Sun &
Public Holidays
Daily
TE1 Woodlands North

Station Layout

L1 Street level Bus stops, Taxi stand, pick-up/drop-off point
B1 Concourse Faregates, Ticketing machines, Passenger Service Centre
B? Platform ? Thomson-East Coast Line towards TE1 Woodlands North
Platform ? Thomson-East Coast Line towards TE1 Woodlands North
B? Platform ? Downtown Line towards DT1BP6 Bukit Panjang
Platform ? Downtown Line towards DT1BP6 Bukit Panjang

Platforms

Thomson-East Coast Line (B?):
MRT_rail (2)
Platform ?: Thomson-East Coast Line towards TE1 Woodlands North via TE30 Bedok South (←) | Towards East Coast Integrated Depot (→)
Platform ?: Thomson-East Coast Line towards TE1 Woodlands North via TE30 Bedok South (←) | From East Coast Integrated Depot
MRT_rail (2)
Downtown Line (B?):
Platform ?: Downtown Line Towards DT1BP6 Bukit Panjang via DT36 Xilin (→) | Towards / From East Coast Integrated Depot
Platform ?: Downtown Line Towards DT1BP6 Bukit Panjang via DT36 Xilin (→) | Towards / From East Coast Integrated Depot

Sungei Bedok station has four platforms over two levels, arranged in an island platform arrangement, with the Thomson-East Coast Line platforms one floor above the Downtown Line platforms. Both platforms are utilized for train turnarounds. Full-height Platform screen doors isolate the air-conditioned station from the tunnel environment, enhancing commuter safety and station comfort.

Passenger Information Systems, which are plasma display screens located at each platform, display expected train arrival times and key messages. Tactile flooring helps to guide the visually-handicapped from the platform to the station exits.

Concourse

The concourse features faregates for automatic fare collection and provides access between paid and unpaid areas of the station, with at least one bidirectional wide-swinging gate for the benefit of passengers-in-wheelchairs and those carrying bulky items or travelling with prams.

General Ticketing Machines allow commuters to purchase tickets for single or multiple journeys, and along with Top-up Machines, offer contactless card transactions. The station office functions as a Passenger Service Centre, and is staffed during operating hours, where commuters may make travel inquiries or perform card transactions using cash payment.

A public toilet is located in the unpaid area of the concourse.

Underground Bicycle Parking

An underground bicycle parking space will be provided as part of Sungei Bedok MRT Station.

Civil Defence shelter

Sungei Bedok station is one of seven stations along the Thomson-East Coast Line (East Coast stretch) designated as Civil Defence (CD) shelters, which will be activated in times of national emergency. Apart from reinforced construction, the stations are designed and equipped with facilities to ensure the shelter environment is tolerable for all shelterees during shelter occupation. These facilities include protective blast doors, decontamination facilities, ventilation systems, power and water supply systems and a dry toilet system.

The other CD shelters are Tanjong Rhu, Marine Parade, Marine Terrace, Siglap, Bayshore and Bedok South stations.

Art in Transit: TBC

Exits

Sungei Bedok MRT station will likely have three exits leading to ground level. More details will be confirmed closer to the opening of the station.

Exit Location Nearby

Station Amenities

  • Public toilets at Concourse

Safety Features

  • Emergency Train Stop buttons on the station platform, when activated, will prevent approaching trains from entering the station, and any train already stopped at the platform will be prevented from moving off.
  • Emergency telephones at station platforms and the intercom system inside the lifts enable commuters to communicate with station staff in the Passenger Service Centre.
  • Emergency door handles allow the platform doors to be opened manually from the train-side in the event of failure.
  • Fire Extinguishers in various locations
  • All escalators equipped with Emergency Stop buttons

Transport Connections (TBC)

Rail Bridging Services (TBC)


Construction

Contract T312 for the Sungei Bedok Station and Tunnels for Thomson-East Coast Line was awarded to KTC Civil Engineering & Construction Pte Ltd for approximately S$417.5 million in June 2016.

Land formerly occupied by the Laguna National Golf Course was acquired to build the station.

Future Developments


Major Incidents
